Seamless Energy Integration: SPF 3500TL LVM-US, a highly versatile and innovative solution for your energy needs. With an integrated MPPT charge controller and the ability to work with or without a battery, this inverter ensures you have power whenever you need it. CSA approval gives you a peace of mind.
High-Capacity and Flexible Input: Boasting a PV input voltage up to 280VDC and the option to connect a generator, this inverter provides a flexible approach to energy management. Choose between grid or solar input priority based on your requirements and enjoy a configurable energy experience.
Smart Connectivity and Expansion: The SPF 3500TL LVM-US supports WIFI/GPRS for remote monitoring, keeping you connected to your energy system wherever you are. With support for parallel operation, expand your system's capacity up to a staggering 21kW for larger energy demands. Parrallel connection of two SPF3500 can give you 110V and 240V A/C output.
Intelligent Power Management: This inverter smartly utilises PV and grid power or generator to jointly power the load if solar energy is insufficient, ensuring you're never without power. Customize your energy usage with flexible scheduling for charging and discharging times according to your needs.
Robust and Efficient Design: Engineered for peak performance, the SPF 3500TL LVM-US delivers up to 3500W of pure sine wave output, with a peak efficiency of 90%.
What Can It Power?
Empower your home or business with the reliable and expandable Growatt Off-Grid Storage Inverter SPF 3500TL LVM-US – your smart solution to modern energy demands.
| Specification | Details |
|---|---|
| Battery Voltage | 51.2VDC |
| Battery Type | Lithium/Lead-acid |
| Inverter Output | Rated Power: 3500VA 3500W Parallel Capability: Yes, 6 units maximum AC Voltage Regulation (Battery Mode): 100Vac/110Vac/120Vac @ 50/60Hz Surge Power: 6000VA Efficiency (Peak): 90% Waveform: Pure Sine Wave Transfer Time: 10ms typical, 20ms max |
| Solar Charger | Maximum PV Array Power: 4000W MPPT Range @ Operating Voltage: 120VDC – 225VDC Maximum PV Array Open Circuit Voltage: 280VDC Maximum Solar Charge Current: 80A |
| AC Charger | Charge Current: 40A AC Input Voltage: 120VAC Selectable Voltage Range: 95-140VAC (For Personal Computers); 65-140VAC (For Home Appliances) Frequency Range: 50Hz/60Hz (Auto sensing) |
| Physical | Protection Degree: IP20/NEMA Type1 Dimension (W/H/D): 330/485/135mm Net Weight: 12kg |
| Operating Environment | Humidity: 5% to 95% Relative Humidity (Non-condensing) Operating Temperature: 0°C - 50°C (32°F - 122°F) Storage Temperature: -15°C - 60°C (-5°F - 140°F) |
| Warranty | 2 Years |
| Certifications | UL STD.1741, CSA STD CSA C22.2 No.107.1 |
The Growatt Off-Grid Storage Inverter SPF 3500TL LVM-US has a rated power of 3500VA/3500W, making it suitable for a wide range of appliances and electronic devices.
Yes, the Growatt SPF 3500TL LVM-US can operate without a battery, directly powering your appliances from solar panels or the grid.
The maximum PV array open circuit voltage for the Growatt Inverter is 280VDC, accommodating a robust solar array setup.
Indeed, the Growatt SPF 3500TL LVM-US supports parallel operation, allowing for capacity expansion up to 21kW with a maximum of 6 units connected together.
WIFI/GPRS remote monitoring is available for the Growatt SPF 3500TL LVM-US, offering you the convenience to monitor and manage your inverter remotely.
The Growatt Off-Grid Storage Inverter SPF 3500TL LVM-US measures 330 x 485 x 135mm (W x H x D) and weighs 12kg, making it a compact and manageable size for installation.
Yes, it features an equalization charging function to balance the battery cells and extend the battery lifespan.
The Growatt SPF 3500TL LVM-US comes with a 2-year warranty, ensuring reliable performance and customer satisfaction.
The inverter offers configurable grid or solar input priority via settings, allowing you to choose the most efficient source of power as needed.
