A comprehensive and powerful solution for residential solar energy needs. This robust system combines the efficiency of the Growatt 3.8kW MIN 3800TL-XH-US Grid-Tie Inverter, and the high-performance 4400W Rigid Bifacial Solar Panels to provide an unrivaled off-grid experience.
Product Features
Growatt 3.8kW MIN 3800TL-XH-US Grid-Tie Inverter:
ROCKSOLAR 440W Monocrystalline Bifacial Solar Panel (x10):
| Inverter Specification | Details |
|---|---|
| Manufacturer | Growatt |
| Model | MIN 3800TL-XH US (WIFI/LAN+TIGO) |
| Rated Power Output [W] | 3800 |
| Length [mm (in)] | 569 mm (22.41 in) |
| Width [mm (in)] | 400 mm (15.75 in) |
| Depth [mm (in)] | 170.5 mm (6.98 in) |
| Weight [kg (lb)] | 17.4 kg (38.36 lb) |
| Workmanship Warranty Period [Years] | 10 |
| Inverter Type | Hybrid inverter |
| Maximum/Peak Efficiency [%] | 98 |
| CEC weighted efficiency @ 240V [%] | 97 |
| Transformer / Transformerless | Transformerless |
| DC Power Rating [W] | 7600 |
| Nom. DC Voltage [V] | 360 |
| Max. Input Power [W] | 7600 |
| Max. Input Voltage [V] | 600 |
| Min. DC voltage / start voltage [V] | 50 |
| Number of DC String Inputs (Inlets) | 4 |
| Number of MPP Trackers | 2 |
| Max. Input Power per MPPT [W] | 3800 |
| Max. Input Voltage per MPPT [V] | 600 |
| Max. Input Current per MPPT [A] | 16.9 |
| Voltage Lower Limit for MPP Range [V] | 50 |
| Voltage Upper Limit for MPP Range [V] | 550 |
| DC Disconnection Type | Integrated |
| Reverse-Polarity Protection | Yes |
| Ground-Fault Isolation Detection | Yes |
| AC Power Rating [W] | 3800 |
| Nominal AC Power [W] | 3800 |
| Max. AC Power [W] | 3800 |
| AC voltage range [V] | 208V: 183-229V / 240V: 211-264V |
| AC grid frequency [Hz] | 60 |
| Max. output current [A] | 16 |
| Nominal AC Voltage [V] | 208/240 |
| Maximum AC Voltage Range [V] | 264 |
| Nominal AC Frequency [Hz], range [Hz-Hz] | 60 |
| AC Connection Type | L1/L2/N/PE |
| AC Current Distortion [THD%] | <3% |
| AC Input Wire Gauge Range [AWG] | 6 AWG - 8 AWG |
| Sleep (Night) Consumption [W] | <5W |
| NEMA Enclosure Rating | NEMA4X (IP65) |
| Cooling Method | Natural Convection |
| Ambient Temperature Range [°C(°F)] | -25°C to +60°C (-13°F to +140°F) |
| Operating Humidity [%] | 0~95% |
| Operating Altitude [ft/m] | 9843ft (3000m) |
| Display | OLED |
| Communication | RS485 included, WiFi/4G Optional |
| Basic Warranty [Years] | 10 |
| Warranty Extension Options [Years] | 15,20 |
| Compliances | IEEE1547, CA Rule21, Rule14 (HECO Compliant), FCC Part15 Class B, UL1741, UL1741SA,CSA C22.2, UL1699B, UL1741 CRD |
| AC grid range [Hz] | 45-65 |
| Max. recommended PV power (@ module STC) | 7600 |
| Solar Panel Specification | Details |
|---|---|
| Panel Type | Monocrystalline Bifacial |
| Power Output | 440W |
| Maximum Power Voltage | 32.98V |
| Cell Efficiency | 22.57% |
| Frame Material | Aluminum |
| Dimensions | 1722mm x 1134mmX30mm |
| Weight | approx. 25-30 lbs |
| Operating Temperature | -40°C to +85°C |
| Waterproof Rating | IP65 |
| Front Glass | High light transmittance, low-iron tempered glass |
| Bypass Diodes | Integrated |
| Connectors | MC4 |
| Cable Length | Varies depending on the brand (approx. 3-6 ft) |
| Mounting Hole Locations | Pre-drilled |
| Service Life | 30 years or more |
| Warranty | 12 years |
