Unlock the full potential of solar power with the ROCKSOLAR 400W Rigid Solar Panel Kit. Perfect for high-demand applications, this kit offers top-tier efficiency and durability for both off-grid and on-grid setups, including homes, RVs, and boats.
The ROCKSOLAR 400W Solar Panel merges exceptional power with reliability, making it a smart choice for energy independence and eco-friendly living.
The 40A MPPT Charge Controller optimizes solar energy conversion, providing superior performance and extended battery life for your solar system.
400W 12V Rigid Solar Panel: One panel with the dimensions of 1722mm x 1134mm x 30mm
40A MPPT Solar Charge Controller: Size: 150 x 200 x 50 mm; Weight: 300 g
By pairing the ROCKSOLAR 400W Solar Panel with the 40A MPPT Charge Controller, you're equipped with a powerful, sustainable, and efficient solar solution, meeting today's high energy demands with an eye on the future.
| 400W Panel | Details |
|---|---|
| Panel Type | Monocrystalline |
| Power Output | 400W-420W |
| System Voltage | 1000V |
| Cell Efficiency | 20.7% |
| Frame Material | Anodized Aluminum |
| Dimensions | 1722mm x 1134mm x 30mm |
| Weight | 22 kg |
| Operating Temperature | -40°C to +85°C |
| Waterproof Rating | IP68 |
| Front Glass | Anti-reflective tempered glass |
| Bypass Diodes | Integrated |
| Connectors | MC4 |
| Service Life | 25 years |
| Warranty | 10 years |
| 40 MPPT Charge Controller | Details |
|---|---|
| Model | POW-Keeper1240 |
| PV Input | Max Open Voltage of PV Module: 100Vdc |
| MPP Tracking Efficiency | 99.50% |
| MAX PV POWER | 520W for 12V system, 1040W for 24V system |
| Charge Mode | 3 Stage Charge Algorithm |
| Battery Type | Lithium and Lead Acid Battery |
| Nominal System Voltage | 12/24V |
| Rated Charging Current | 40A |
| Battery Voltage Range | 8~32V |
| High Voltage Disconnection | 16V (24V x 2) |
| Duration for Absorption Charging | 2 hours |
| Charge Loop Voltage Drop | ≤0.29V |
| Self-consumption | ≤ 9.2mA 12V; ≤ 11.7mA 24V |
| Equalized Charging Voltage | AGM: 14.6V; GEL: No; FLd: 14.8V |
| Absorption Charging Voltage | AGM: 14.4V; GEL: 14.2; FLd: 14.6V |
| Floating Charging Voltage | AGM/ GEL/ FLd: 13.8V |
| Low Voltage Re-connection (LVR) | AGM/ GEL/ FLd: 12.6V |
| Low Voltage Disconnection (LVD) | AGM/ GEL/ FLd: 10.8V |
| Operating Temperature Range | -20℃~55℃ (Full rated current) |
| LCD Temperature Range | -20℃~70℃ |
| Humidity Range | ≤95% No condensation |
| Protection Class | IP30 |
| Dimensions | 123*178*48 mm |
| Installation Hole | 108*120 ∅5 |
The kit contains two 200W 12V rigid solar panels, a 20A MPPT solar charge controller, necessary connecting cables, mounting hardware, and a user manual for a complete solar energy system setup.
Yes, the included 20A MPPT controller is versatile, capable of supporting various battery types such as Lithium, AGM, Gel, and lead-acid, providing flexibility for different energy storage needs.
The 20A MPPT controller enhances solar energy conversion efficiency significantly compared to PWM controllers. It maximizes the energy harvested from the solar panels, ensuring efficient battery charging.
The 400W solar panels are built to withstand various environmental stresses, including high temperatures. They are designed to offer consistent performance and durability across different climatic conditions.
Each 200W solar panel in the kit typically requires about 1580mm x 808mm of space, so for the full 400W, ensure you have double this area available for an unobstructed installation.
Indeed, the MPPT controller is designed to charge batteries efficiently and safely, helping to prolong their overall lifespan by preventing overcharging and ensuring optimal charging profiles.
Yes, this kit is perfect for off-grid setups, including remote cabins, RVs, and boats. It provides a reliable and sustainable power source in areas without access to the electrical grid.
Maintenance typically involves periodically cleaning the solar panels to remove debris, dust, and snow. Regular inspection of the mounting system and electrical connections for safety and efficiency is also recommended.
Solar panels can last more than 25 years with proper care and maintenance. The MPPT controller and other components generally have a shorter lifespan but should function effectively for several years with proper usage.
Yes, the 400W solar panel kit contributes to sustainable and renewable energy use, significantly reducing carbon footprint and reliance on fossil fuels for energy generation.
Ensure all electrical connections are secure and the panels are solidly mounted. Always follow the safety guidelines provided in the manual. If you're unfamiliar with solar installations, professional installation is recommended for safety and optimal performance.
While solar panel output naturally decreases in cloudy conditions, the MPPT controller optimizes the available solar energy, ensuring that the batteries receive the maximum possible charge even on overcast days.
