A comprehensive and powerful solution for residential solar energy needs. This robust system combines the efficiency of the Growatt 11.4kW MIN 10000TL-XH-US Grid-Tie Inverter, and the high-performance 13200W Rigid Bifacial Solar Panels to provide an unrivaled energy independence experience.
Product Features
Growatt 11.4kW MIN 11400TL-XH-US Grid-Tie Inverter:
ROCKSOLAR 440W Monocrystalline Bifacial Solar Panel (x30):
| Inverter Specification | Details |
|---|---|
| Manufacturer | Growatt |
| Type | Grid-Tie / Battery Storage |
| AC Power | 11.4kW |
| Max PV Input Power | 22.8kW |
| MPP Trackers | 4 |
| MPPT Voltage Range | 235~500V |
| Max Efficiency | 98.5% |
| Compatible Battery | Growatt ARO HV Battery / LG Prime(Gen3) Battery |
| Warranty | 10 Years |
| Communications | CAN2.0, RS485, SUNSPEC / APP, Website |
| Certificate | UL1741, UL1741SA, UL1998, UL1699B, CSA C22.2, CA Rule21, UL9540 |
| PV Input | |
| Max PV Input Power | 22.8 kW |
| Max Input Voltage | 600V |
| Full Load Voltage Range | 235~500V |
| Max Input Current per MPTT | 13.5A |
| Max Short-circuit Current per MPTT | 16.9A |
| MPP Trackers | 4 |
| Strings per MPP Tracker | 2 |
| Battery Connection | |
| Battery Voltage Range | 360~550V |
| Rated Battery Voltage | 400V |
| I/O DC Current | 34A/34A |
| I/O DC Power | 11.7kW |
| AC Output (Grid) | |
| Nominal Power | 11.4kW |
| Max Output Current | 48A |
| Nominal AC Voltage | 208/240V |
| General Data | |
| Dimensions (H*W*D) | 15.8*25.2*7.4 inch (400*638*187mm) |
| Weight | 45.2lbs (20.5kg) |
| Installation | Indoor, Outdoor, Wall-mounted |
| Monitoring Module | WiFi+ LAN, 4G(Optional) |
| Solar Panel Specification | Details |
|---|---|
| Panel Type | Monocrystalline Bifacial |
| Power Output | 440W |
| Maximum Power Voltage | 32.98V |
| Cell Efficiency | 22.57% |
| Frame Material | Aluminum |
| Dimensions | 1722mm x 1134mmX30mm |
| Weight | approx. 25-30 lbs |
| Operating Temperature | -40°C to +85°C |
| Waterproof Rating | IP65 |
| Front Glass | High light transmittance, low-iron tempered glass |
| Bypass Diodes | Integrated |
| Connectors | MC4 |
| Cable Length | Varies depending on the brand (approx. 3-6 ft) |
| Mounting Hole Locations | Pre-drilled |
| Service Life | 30 years or more |
| Warranty | 12 years |
