Introducing the Advanced Home Solar Storage Kit - 10kW Energy Storage with 12kW Inverter + 4400W Solar Array, a premium solar energy systems designed for 120V/240V 100AMP house, cottage, cabin, etc. This all-encompassing kit features GROWATT's SPF 12000T DVM-US MPV, a 12kW inverter known for its seamless energy integration and intelligent power management, alongside two 5kWh batteries for a total energy storage of 10kW, and a robust 4400W solar panel array comprised of 10 high-efficiency 440W Monocrystalline N Type Topcon Bifacial panels.
Key Highlights:
Growatt AXE 5.0L-C1 5kWh Battery (x2):
Growatt SPF 12000T DVM-US MPV Inverter:
440W Bifacial Monocrystalline Solar Panel (x10):
With the Growatt Ultimate Home Solar Storage Kit, achieve energy independence, reduce electricity bills, and enjoy the assurance of a reliable power supply. Experience the combined benefits of modern solar technology and battery storage in one seamless package.
| Growatt AXE 5.0L-C1 5kWh Battery | Details |
|---|---|
| Model | Growatt AXE 5.0L-C1 |
| Energy Capacity | 5.0kWh |
| Max Charge/Discharge Power | 3kWh |
| Max Charge/Discharge Current | 60A |
| Dimensions | 650 x 350 x 165mm (W x D x H) |
| Weight | 42kg |
| Nominal Voltage | 51.2V |
| Warranty | 10 years |
| Battery Type | Cobalt Free Lithium Iron Phosphate (LFP) |
| Operating Voltage Range | 48 - 57.6V |
| Installation | Floor installation |
| Operation Temperature | 0°C-50°C/32-122°F |
| DoD | 92% |
| Parallel Capability | Multi-cluster AXE battery system in parallel, Max. 8 clusters (Max. 400kWh) |
| Communication Port | CAN/RS485 |
| Performance Warranty | 10 years |
| Certification | CE, ROHS, UL1973+FCC, UN38.3 + IP65 |
| Growatt Off-Grid Storage SPF 12000T DVM-US | Details |
|---|---|
| Battery Voltage | 48VDC |
| Battery Type | Lithium/Lead-acid |
| Inverter Output (Rated Power) | 12KW |
| Surge Rating | 36KW |
| Waveform | Pure sine wave/ same as input (bypass mode) |
| Nominal Output Voltage RMS | 104-110-115-120/208-220-230-240VAC(optional) |
| Output Frequency | 50Hz/60Hz +/-0.5 Hz |
| Inverter Efficiency (Peak) | 88% |
| Transfer Time | 10ms |
| Solar Charger (Maximum PV Charge Current) | 60A |
| Maximum PV Array Power | 7000W |
| AC Input Voltage | 240VAC |
| Max. Charging Current | 100A |
| Protection Degree | IP20 |
| Dimensions (W/H/D) | 360/650/225mm |
| Weight | 75kg |
| Operating Environment (Temperature Range) | 0°C to 50°C |
| Warranty | Complies with UL STD.1741, CSA STD CSA C22.2 No.107.1 |
| 440W Bifacial Solar Panel | Details |
|---|---|
| Panel Type | Monocrystalline N Type Topcon Bifacial |
| Power Output | 440W |
| Maximum Power Voltage | 32.98V |
| Cell Efficiency | 22.57% |
| Frame Material | Aluminum |
| Dimensions | 1722mm x 1134mmX30mm |
| Weight | approx. 25-30 lbs |
| Operating Temperature | -40°C to +85°C |
| Waterproof Rating | IP65 |
| Front Glass | High light transmittance, low-iron tempered glass |
| Bypass Diodes | Integrated |
| Connectors | MC4 |
| Cable Length | Varies depending on the brand (approx. 3-6 ft) |
| Mounting Hole Locations | Pre-drilled |
| Service Life | 30 years or more |
| Warranty | 12 years |
The kit includes a 12kW inverter, two 5kWh batteries for a total of 10kW energy storage, and a solar panel array capable of producing 22000W-28000W of power daily.
Yes, this kit is designed for both off-grid and on-grid functionality, offering unparalleled versatility for various living situations and energy needs.
Absolutely, the kit's modular nature allows for easy expansion. Additional batteries and solar panels can be integrated to enhance the system's storage capacity and power generation, respectively.
Maintenance needs are minimal, primarily involving regular checks to ensure component functionality and cleaning the solar panels to maintain optimal energy production.
The 12kW inverter utilizes intelligent power management to allocate solar energy effectively between immediate use and storage, supplementing with grid power as necessary to ensure a constant energy supply.
Yes, the system supports optional WIFI/GPRS connectivity, allowing for remote monitoring and management. This feature enables you to oversee and adjust your energy usage conveniently from any location.
Each component of the kit is backed by its own warranty, providing comprehensive protection and assurance for your investment over the long term.
While the kit is designed for user-friendly installation, it is recommended that installation be carried out by professionals to ensure the system's optimal performance and safety.
