90700120
Introducing the Ultimate Home Solar Storage Kit, a comprehensive and powerful solution designed for 120V/30AMP Cottage, Cabin and RV. This robust system combines the efficiency of the Growatt Off-Grid Storage Inverter SPF 3500TL LVM-US, the reliability of the Growatt AXE 5.0L-C1 5kWh Battery, and the high-performance 2640W Rigid Bifacial Solar Panels to provide an unrivaled off-grid experience.
Engineered for seamless integration, the system ensures that your home can run independently of the grid, whether as a primary power source or as a backup during outages. It's an ideal setup for environmentally conscious homeowners looking to reduce their carbon footprint and harness the power of the sun.
Product Features
Growatt AXE 5.0L-C1 5kWh Battery:
Growatt Off-Grid Storage Inverter SPF 3500TL LVM-US:
ROCKSOLAR 440W Monocrystalline Bifacial Solar Panel (x6):
With the Growatt Ultimate Home Solar Storage Kit, achieve energy independence, reduce electricity bills, and enjoy the assurance of a reliable power supply. Experience the combined benefits of modern solar technology and battery storage in one seamless package.
| Growatt AXE 5.0L-C1 5kWh Battery | Details |
|---|---|
| Model | Growatt AXE 5.0L-C1 |
| Energy Capacity | 5.0kWh |
| Max Charge/Discharge Power | 3kWh |
| Max Charge/Discharge Current | 60A |
| Dimensions | 650 x 350 x 165mm (W x D x H) |
| Weight | 42kg |
| Nominal Voltage | 51.2V |
| Warranty | 5 years |
| Battery Type | Cobalt Free Lithium Iron Phosphate (LFP) |
| Operating Voltage Range | 48 - 57.6V |
| Installation | Floor installation |
| Operation Temperature | 0°C-50°C/32-122°F |
| DoD | 92% |
| Parallel Capability | Multi-cluster AXE battery system in parallel, Max. 8 clusters (Max. 400kWh) |
| Communication Port | CAN/RS485 |
| Performance Warranty | 10 years |
| Certification | CE, ROHS, UL1973+FCC, UN38.3 + IP65 |
| Growatt Off-Grid Storage Inverter SPF 3000~3500TL LVM-US | Details |
|---|---|
| Battery Voltage | 48VDC |
| Battery Type | Lithium/Lead-acid |
| Inverter Output | Rated Power: 3500VA 3500W Parallel Capability: Yes, 6 units maximum AC Voltage Regulation (Battery Mode): 100Vac/110Vac/120Vac @ 50/60Hz Surge Power: 6000VA Efficiency (Peak): 90% Waveform: Pure Sine Wave Transfer Time: 10ms typical, 20ms max |
| Solar Charger | Maximum PV Array Power: 4000W MPPT Range @ Operating Voltage: 120VDC – 225VDC Maximum PV Array Open Circuit Voltage: 280VDC Maximum Solar Charge Current: 80A |
| AC Charger | Charge Current: 40A AC Input Voltage: 120VAC Selectable Voltage Range: 95-140VAC (For Personal Computers); 65-140VAC (For Home Appliances) Frequency Range: 50Hz/60Hz (Auto sensing) |
| Physical | Protection Degree: IP20/NEMA Type1 Dimension (W/H/D): 330/485/135mm Net Weight: 12kg |
| Operating Environment | Humidity: 5% to 95% Relative Humidity (Non-condensing) Operating Temperature: 0°C - 50°C (32°F - 122°F) Storage Temperature: -15°C - 60°C (-5°F - 140°F) |
| Warranty | 2 Years |
| 440W Solar Panel Specification | Details |
|---|---|
| Panel Type | Monocrystalline Bifacial |
| Power Output | 440W |
| Maximum Power Voltage | 32.98V |
| Cell Efficiency | 22.57% |
| Frame Material | Aluminum |
| Dimensions | 1722mm x 1134mmX30mm |
| Weight | approx. 25-30 lbs |
| Operating Temperature | -40°C to +85°C |
| Waterproof Rating | IP65 |
| Front Glass | High light transmittance, low-iron tempered glass |
| Bypass Diodes | Integrated |
| Connectors | MC4 |
| Cable Length | Varies depending on the brand (approx. 3-6 ft) |
| Mounting Hole Locations | Pre-drilled |
| Service Life | 30 years or more |
| Warranty | 12 years |
The kit includes a Growatt Off-Grid Storage Inverter SPF 3500TL LVM-US, a Growatt AXE 5.0L-C1 5kW Battery, 6 ROCKSOLAR 440W Bifacial Solar Panels, and all necessary cables and manuals for installation.
This system can generate up to 9000W daily from the solar panels and store 5kW of energy in the battery, with the option to expand the storage capacity up to 400kWh with additional batteries.
The system is designed for straightforward installation. The battery modules can be easily stacked, and clear instructions are provided. Technical support is available if you require assistance.
The system requires minimal maintenance, mainly keeping the solar panels clean and ensuring all connections remain secure. The system's components are designed for longevity and performance.
Yes, the system's modular design allows for easy expansion. You can add more batteries to increase storage capacity or more solar panels to generate additional power.
The solar panels come with a 10-year manufacturer warranty, the battery has a 5-year warranty, and the inverter comes with a 2-year warranty.
Absolutely, this system is ideal for off-grid living, providing a reliable source of energy to power your home essentials and more.
The Growatt storage inverter and battery are equipped with monitoring capabilities, allowing you to track performance and manage your system remotely.
The system includes a range of safety features, such as overcharge and over-discharge protection, temperature control, and advanced battery management systems to ensure safe operation.
Yes, the system is designed to provide uninterrupted power supply during outages, making it a reliable backup power source for your home.
